Votator
keyword：
Continuous Band Dryer
Votator
Model: JT-fixed, JTB-oscillating (patent)
Characteristics：Votator is for application in the gelatin gelled for drying. It is a scraped surface heat exchanger. The gelatin flows through a jacket cylinder containing a rotating central shaft on which the scrape blades are mounted with the flowing of cooling medium in jacket. The gelatin is chilled and gelled and being extruded in noodle form and spread evenly onto dryer by self-oscillating. It keeps the gelatin free of being polluted by bacteria during convey by belt conveyer. The oscillating votator is the patent newly developed by our company.
Capacity: Gelatin 750~2000T/Y
Control Mode: Automatic control, temperature auto-control, automatic oscillating
The Main Fittings: Scraped surface heat exchanger, oscillating system, feed pump, frame structure, pipeline and temperature are automatic control. It is made of high quality stainless steel.
Technical Parameters:
|
Item |
JTB-750 |
JTB-1000 |
JTB-1500 |
JTB-2000 |
|
|
Heat exchange area |
m2 |
0.5 |
0.8 |
0.9 |
1.4 |
|
Product rate |
kg/h |
110 |
150 |
220 |
300 |
|
Feed rate |
kg/h |
400 |
600 |
800 |
1200 |
|
Feed concentration |
% |
|
24~30 |
|
|
|
Chilled brine -10℃ |
M3/h |
35 |
40 |
60 |
80 |
|
Power |
kw |
15 |
18 |
22 |
22 |
